What to Look for When Buying a Used Ace Micromatic
Ace Micromatic machines are built for high-volume production at an accessible price point, and most used units come out of automotive and general engineering shops, so a careful inspection pays off.
On Jobber and LT series lathes, check the spindle and turret first. Measure spindle runout at the chuck and listen for bearing noise across the full RPM range. Index the turret through every station and verify repeatability; on LM (live tooling) models, run each driven station under power. Inspect ballscrews and guideways for backlash and confirm smooth tailstock quill actuation.
On AMS machining centers, verify spindle, ATC, and way systems. Test spindle taper condition, check thermal behavior after warm-up, and cycle the automatic tool changer through every pocket. On twin-spindle Gemini machines, confirm both spindles hold matching tolerances. Review axis backlash and look for scoring on guideways.
On Micromatic grinders, inspect the wheel spindle and hydraulics. Wheel spindle condition determines surface finish, so check for vibration and verify the balancing system. On centerless models, inspect the regulating wheel drive and work rest blades, and confirm hydraulics hold pressure without leaks.
Confirm the control platform and parts support. Ace Micromatic builds machines on Fanuc, Siemens, Mitsubishi, Syntec, and Delta controls depending on model and market. Fanuc-equipped machines are the easiest to support in North America, so verify the control and parts availability before purchase.
Ace Designers CNC Lathes
Jobber Series
The Jobber series is the foundation of the brand: India's benchmark standard CNC lathe with over 10,000 machines installed. The range runs from the compact Jobber Junior and J 300 through the Jobber XL and Super Jobber (the most common models on the used market) to the next-generation Jobber Evo (JE 06/08 and SJE 06/08/10). These 2-axis lathes are prized for reliability, simple operation, and low operating cost.
LT Series & Turn-Mill
The LT series (led by the LT-2 and LT-2 XL) provides larger-capacity turning with live tooling (LM), sub-spindle, and Y-axis configurations. The Vantage turn-mill series adds multi-axis capability for complete part machining. Slant-bed chuckers (LJ 100, LS-04/06/08, SLC series) handle small disc-type components at high production rates.
VTL Vertical Lathes
Ace Designers VTL series vertical lathes (VTL-25, VTL-45 XL, VTL-50, VTL-400) handle chucking work such as brake components, gear blanks, and bearing housings.
AMS Machining Centers
MCV Vertical Machining Centers
The MCV series (MCV-300 through MCV-800) is the AMS workhorse VMC line, built on cast iron structures with BT-40 spindles (BT-50 on larger variants). The MCV-450 and MCV-650 are the most widely traded. The ACER-50 handles heavier cuts, while Gemini twin-spindle VMCs double output for production cells.
Horizontal & Double-Column Machines
AMS horizontal machining centers include the MCH series (MCH-400 through MCH-800) and CMH series with pallet changers for production work. DC series double-column machines cover large die, mold, and plate work, and the GV-60-5C provides 5-axis capability.
Micromatic Grinding Machines
Micromatic Grinding Technologies builds CNC cylindrical, centerless, internal, and universal grinders, plus crankshaft and special-purpose grinding machines. Hydraulic models serve shops that need proven grinding capacity without CNC complexity. These machines are common in automotive, bearing, and pump shaft production.
How to Sell Your Used Ace Micromatic
Demand for used Ace Micromatic machines is growing as more US shops discover the brand's value. Jobber lathes, MCV machining centers, and Micromatic grinders all find ready buyers, particularly with Fanuc controls and maintenance records.
Resell CNC buys used Ace Micromatic machines — every model, every group company, nationwide.
- Contact us — call (844) 478-8181 or email sales@resellcnc.com.
- Free appraisal within 24 hours — no obligation.
- Accept the offer — we handle rigging, transport, and logistics.
Frequently Asked Questions About Used Ace Micromatic Machines
What is the difference between Ace Micromatic, Ace Designers, and AMS?
They are all part of the same group. Ace Designers builds CNC lathes, Ace Manufacturing Systems (AMS) builds machining centers, Micromatic Grinding builds grinders, and Micromatic Machine Tools handles sales and service. A used machine may carry any of these names on its badge.
Are used Ace Micromatic machines reliable?
Yes. Ace Micromatic is India's largest machine tool builder, and the Jobber series earned its reputation through standardized production and proven reliability across more than 10,000 installations. Machines use quality components, including Fanuc and Siemens controls.
What CNC controls do Ace Micromatic machines use?
Most machines use Fanuc controls, which are the easiest to support in North America. Depending on model and market, machines are also offered with Siemens, Mitsubishi, Syntec, and Delta controls.
Can I get parts and service for Ace Micromatic machines in the US?
Yes. Ace Micromatic machines are distributed and supported in the US through a dedicated machinery partner network, and Fanuc-based controls and common wear parts are serviceable by independent technicians nationwide.
What Ace Micromatic models hold their value best?
Super Jobber and Jobber XL lathes, MCV-450 and MCV-650 machining centers, and late-model CNC grinders with Fanuc controls hold value well. Live tooling and sub-spindle options command a premium. Call (844) 478-8181 for valuations.
What industries use Ace Micromatic machines?
Automotive component production is the largest user base, followed by general engineering, pumps and valves, hydraulics, aerospace, medical, and die and mold shops.
Does Resell CNC offer financing on used Ace Micromatic machines?
Yes. Resell CNC offers flexible financing options to help your business acquire the equipment it needs. Contact us at (844) 478-8181 to discuss terms.
How do I sell my used Ace Micromatic?
Contact Resell CNC at (844) 478-8181 or sales@resellcnc.com. We buy every Ace Micromatic, Ace Designers, AMS, and Micromatic Grinding model, nationwide. Free appraisal within 24 hours.
