What to Look for When Buying a Used Agie Charmilles EDM
Agie Charmilles EDM machines are precision instruments where generator condition, axis accuracy, and dielectric system health directly affect cut quality and surface finish. Here is what to check.
On wire EDM machines, verify the generator, threading, and axis accuracy. Run a test cut and measure dimensional accuracy, surface finish (Ra), and taper consistency. Verify automatic wire threading fires reliably on the first attempt. Check wire tension, speed controls, and guide condition. Test axis positioning by cutting a known geometry. On machines with Automatic Wire Changer (AWC), confirm wire diameter switching.
On sinker EDM machines, test the generator and servo performance. Run a test burn with a known electrode and verify surface finish and dimensional accuracy. Check electrode wear ratio against expected values. Verify Z-axis servo responds smoothly without hunting. On machines with C-axis rotation, test positioning under electrode weight. Confirm the Linear Tool Changer indexes correctly if equipped.
On all EDM machines, inspect the dielectric system and CNC control. Check dielectric fluid condition, filtration, and temperature control. Verify the CNC boots properly and all functions respond. Check generator hours and service history. Confirm System 3R compatibility if the machine will be used with palletized automation.
Wire EDM Machines
CUT E Series
The CUT E 350 and CUT E 600 are entry and mid-range wire EDM machines. The CUT E 350 provides 350 x 250 x 256 mm travels; the CUT E 600 expands to 600 x 400 x 400 mm. Both feature the IPG generator, automatic wire threading, and AC CUT HMI control.
CUT P Series
The CUT P 350, CUT P 550, and CUT P 800 deliver higher speed, accuracy, and automation for production wire EDM. The CUT P series features the ISPG (Intelligent Speed Power Generator), Spark Track technology for real-time spark analysis, and iWire for reduced wire consumption. The CUT P 550 is among the most popular current-generation Agie Charmilles wire machines.
Legacy Wire EDM
Earlier wire machines including the Robofil series (Robofil 240, 290, 310, 440, 510), CUT 20P, CUT 30P, and CUT 200/300/1000 are among the most commonly available used wire EDM machines in North America. Many remain in active production use.
Die-Sinking EDM Machines
FORM E & FORM P Series
The FORM E 350 and FORM E 600 provide compact die-sinking EDM with the ISPG generator and GammaTEC technology for mirror-finish surface quality. The FORM P 350, FORM P 600, and FORM P 900 add enhanced automation, larger work envelopes, and advanced servo control. All current sinker models feature the AC FORM HMI and support System 3R palletization and LTC automation.
Legacy Sinker EDM
Earlier models including the Roboform series (20, 30, 40, 55), FORM 20, FORM 30, and various Agie sinkers remain widely traded, serving die/mold shops and aerospace manufacturers.
Hole Drilling & Automation
The DRILL 20 and DRILL 300 provide high-speed EDM hole drilling for start holes, turbine blade cooling holes, and fuel injection nozzles. System 3R tooling, pallets, and automation solutions are integral to the Agie Charmilles ecosystem, providing repeatable workholding and robotic cell integration for unmanned operation.
How to Sell Your Used Agie Charmilles
Agie Charmilles EDM machines hold strong resale value thanks to the brand's Swiss precision reputation, large installed base, and consistent demand. CUT P wire machines, FORM P sinkers, and legacy Robofil and Roboform models are all in steady demand.
Resell CNC buys used Agie Charmilles EDM machines, every model, every generation, nationwide.
- Contact us -- call (844) 478-8181 or email sales@resellcnc.com.
- Free appraisal within 24 hours, no obligation.
- Accept the offer -- we handle rigging, transport, and logistics.
Frequently Asked Questions About Used Agie Charmilles EDM Machines
Are used Agie Charmilles machines reliable?
Yes. Agie and Charmilles invented the EDM industry in 1954 and have set the standard ever since. Machines are engineered in Switzerland with generators designed and assembled in-house. Many Robofil and Roboform models from the 1990s and 2000s remain in active production today.
What is the difference between Agie, Charmilles, AgieCharmilles, and GF Machining Solutions?
Agie and Charmilles were separate Swiss EDM manufacturers that merged in 1996 to form AgieCharmilles. In 2013, AgieCharmilles became part of GF Machining Solutions (a division of Georg Fischer AG). Used machines may carry any of these names depending on the year of manufacture.
What CNC controls do Agie Charmilles EDMs use?
Current machines use proprietary controls with the AC CUT HMI (wire) or AC FORM HMI (sinker) interface. Legacy machines use Agievision or earlier proprietary controls. The platform is purpose-built for EDM and includes integrated process databases.
What should I inspect before buying a used Agie Charmilles?
For wire EDM, test cut accuracy, surface finish, auto-threading reliability, and wire guide condition. For sinker EDM, run a test burn and check electrode wear ratio and surface finish. On all machines, inspect the dielectric system, generator hours, and CNC function.
What Agie Charmilles models hold their value best?
CUT P wire machines hold the strongest resale values. FORM P sinkers maintain premium demand. Legacy Robofil and Roboform models retain strong value due to proven reliability. Call (844) 478-8181 for current valuations.
What industries use Agie Charmilles EDM machines?
Die and mold making, aerospace, medical devices, automotive, electronics, watchmaking, and general tool and die operations.
Does Resell CNC offer financing on used Agie Charmilles machines?
Yes. Resell CNC offers flexible financing options. Contact us at (844) 478-8181 to discuss terms.
How do I sell my used Agie Charmilles?
Contact Resell CNC at (844) 478-8181 or sales@resellcnc.com. We buy all Agie Charmilles EDM machines nationwide. Free appraisal within 24 hours.
