What to Look for When Buying a Used Mitutoyo CMM or Vision System
Mitutoyo CMMs and vision systems are precision instruments built to Japanese metrology standards. Used equipment can deliver exceptional value, but there are specific inspection points every buyer should verify.
Inspect air bearings, scales, and granite. On bridge-type CMMs (Crysta-Apex, Strato-Apex, Legex), air bearings on X, Y, and Z must glide smoothly with no binding. Check the granite table for dings, chips, or moisture damage. Verify scales, Mitutoyo uses ABS absolute linear scales on newer machines and glass scales on legacy units. Confirm scale covers are intact and no dust, coolant, or chip contamination is present.
Verify the probe system and controller. Mitutoyo CMMs ship with a variety of probe heads: Renishaw PH10M/PH10T indexing heads, TP20/TP200 touch-trigger probes, SP25M scanning probes, PH20 5-axis heads, or REVO on high-end units. Confirm the probe system matches the controller and all probe modules are present. Vision systems (QV Apex, Hyper QV) use QV camera modules, programmable power turrets, and laser auto-focus. Check objective lenses for damage.
Check software licenses and version. Mitutoyo CMMs run MCOSMOS or MiCAT Planner. Vision systems run QVPAK. Software licenses transfer with the machine but versions matter. Verify current license, dongle presence, and whether MCOSMOS add-on modules (Geopak, Scanpak, Catpak) are included.
Request calibration and service records. CMMs require regular ISO 10360 performance verification. Ask for the most recent calibration certificate (A2LA-accredited preferred), service history through Mitutoyo America, and any history of major repairs. Budget for post-purchase recertification on any used CMM.
Mitutoyo CMM Series Guide
Crysta-Apex Series (General-Purpose Bridge CMM)
The Crysta-Apex S and Crysta-Apex V are Mitutoyo's best-selling bridge-type CNC CMMs. Common model numbers encode X/Y/Z travel in centimeters: Crysta-Apex 544 (500×400×400 mm), 574, 776, 7106, and 9106 (900×1000×600). Features include high-rigidity air bearings, temperature compensation (16° to 26°C), and ABS scales on Crysta-Apex V. Crysta-Apex EX ships with Renishaw PH20 5-axis heads, and Crysta-Apex EX 1200R ships with the REVO probe system.
Strato-Apex Series (High-Accuracy CMM)
The Strato-Apex series (500, 700, 900, 1600) delivers first-term accuracy of 0.9 µm with high-speed scanning. Anti-vibration stands and improved air bearings make these ideal for quality labs and tight-tolerance production inspection.
Legex Series (Ultra-High-Accuracy CMM)
The Legex series (500, 700, 900, 1200) is Mitutoyo's laboratory-grade ultra-high-accuracy CMM, with crystallized-glass scales, 10 nm resolution, and accuracy of 0.28 µm. Ideal for gears, bearings, lenses, and precision dies requiring sub-micron measurement.
MACH In-Line & FALCIO Large-Gantry
The MACH series (MACH V9106, MACH-3A 653, MACH KO-GA-ME) provides in-line shopfloor CMMs for production integration. FALCIO-Apex G 2000/3000 handles large and heavy components in gantry configuration. Legacy Bright, Euro-C, and first-generation Crysta CMMs remain widely traded.
Mitutoyo Quick Vision & Form Measurement
The Quick Vision (QV) family includes QV Apex (standard, in 302, 404, and 606 sizes), Hyper QV (ultra-high accuracy), QV Stream Plus (on-the-fly continuous measurement), QV Active, and QS-L (economy vision with 7× optical zoom). Hyper QV WLI adds white-light interferometry for 3D surface texture analysis. Form measurement: Surftest, Formtracer Avant, Contracer, and Roundtest RA.
How to Sell Your Used Mitutoyo CMM or Vision System
Mitutoyo metrology equipment holds strong resale value thanks to the brand's global reputation, ongoing parts support through Mitutoyo America, and continuing demand from aerospace, medical, and precision manufacturing. Crysta-Apex, Strato-Apex, Legex, and Quick Vision models with recent calibration and documented service command the highest offers.
Resell CNC buys used Mitutoyo equipment nationwide, every model and generation.
- Contact us, call (844) 478-8181 or email sales@resellcnc.com.
- Free appraisal within 24 hours, no obligation.
- Accept the offer, we handle rigging, transport, and logistics.
Frequently Asked Questions About Used Mitutoyo Machines
Are used Mitutoyo CMMs worth buying?
Yes. Mitutoyo is the world's leading metrology manufacturer, and well-maintained CMMs routinely deliver 15 to 20+ years of service. Used Mitutoyo with current calibration, documented service, and up-to-date software can cost significantly less than new while retaining the full accuracy class.
What software do Mitutoyo CMMs use?
Mitutoyo CMMs run MCOSMOS (MCOSMOS 5 is current) with optional modules like Geopak, Scanpak, Catpak, and MiCAT Planner. Vision systems run QVPAK. Confirm license and version before purchase.
What probe systems do Mitutoyo CMMs support?
Mitutoyo CMMs support Renishaw systems including PH10M/PH10T motorized heads, TP20 and TP200 touch-trigger probes, SP25M scanning probes, PH20 5-axis heads, and REVO on premium Crysta-Apex EX. Mitutoyo also offers the MPP-310Q scanning probe and SurfaceMeasure laser probe.
Does a used Mitutoyo CMM need recertification?
Yes. CMMs should be recertified to ISO 10360 performance standards after any move. Budget for A2LA-accredited calibration through Mitutoyo America or an authorized third-party lab. Machines with recent certificates (within 12 months) accelerate initial use.
What is the difference between Crysta-Apex, Strato-Apex, and Legex?
Crysta-Apex is the general-purpose workhorse CMM. Strato-Apex offers higher accuracy (0.9 µm first-term) and speed for quality labs. Legex is the ultra-high-accuracy flagship (0.28 µm) for sub-micron laboratory work.
Are Mitutoyo parts and service still available?
Yes. Mitutoyo America operates regional calibration labs and A2LA-accredited service across North America, with parts and calibration support for most CMM and vision generations in active use.
Does Resell CNC offer financing on used Mitutoyo machines?
Yes. Resell CNC offers flexible financing options. Call (844) 478-8181 to discuss terms.
How do I sell my used Mitutoyo CMM or vision system?
Contact Resell CNC at (844) 478-8181 or sales@resellcnc.com. We buy every Mitutoyo model nationwide: Crysta-Apex, Strato-Apex, Legex, MACH, FALCIO-Apex, Bright, Quick Vision, Hyper QV, QS-L, Surftest, Contracer, and Roundtest. Free appraisal within 24 hours.
