What to Look for When Buying a Used Olympia Machine
Olympia machines are built for heavy-duty machining with high-value components in aerospace, defense, and industrial applications. These machines handle large workpieces, high cutting forces, and demanding tolerances. Here is what to inspect on used units.
On VTLs, test the table, spindle, and live tooling. Verify table flatness and concentricity using a test indicator. Run the table across the full RPM range and check for bearing noise, vibration, and thermal stability. On the V40, the polymer casting base provides superior vibration damping, but verify that the casting is free of cracks or repairs. On V60L and other live-tooled models, test the CAT 50 live spindle at 2,500 RPM for runout and smooth operation. Verify C-axis indexing accuracy. Cycle the automatic tool changer through every position (12 on V40, 32 on V60L) and confirm reliable tool exchange.
On horizontal boring mills, verify the spindle and all axes. Measure the boring spindle runout at the taper and at extension. Test the W-axis quill travel for smooth extension and retraction without deflection. Verify X, Y, and Z axis positioning accuracy and backlash across full travel distances (up to 118 inches on X, 98 inches on Y for HT120X100 models). On machines with 4th-axis rotary tables, test indexing accuracy and table lockup at multiple positions. Verify the table load capacity by checking the bearing condition and hydraulic clamping system.
Test the CNC control and auxiliary systems. Olympia machines use Fanuc CNC controls (18i-T on VTLs, various models on boring mills). Confirm clean power-up, axis referencing, and program execution. Test all G-code and M-code functions. Verify through-spindle coolant delivery if equipped. Check the full enclosure (on VTLs) for integrity, chip conveyor function, and coolant system performance. Inspect way covers for damage or binding.
Evaluate the machine structure and foundation. Olympia machines are heavy (the V60L weighs 58,000 pounds) and require proper foundations. Check for any evidence of settling, cracking, or leveling issues. Verify that the machine is properly leveled and that geometric accuracy (squareness, parallelism, perpendicularity of axes) meets specifications. On polymer casting models (V40), inspect for any delamination or structural issues at joints between polymer and steel components.
Olympia V-Series CNC Vertical Turning Centers
The V40 is Olympia's most widely recognized vertical turning center. With a 39.4-inch table, 48-inch maximum swing, and 54 HP continuous spindle, the V40 delivers exceptional cutting force (6,740 pounds under full ram extension) and table torque (16,660 ft-lb) for its size class. The polymer casting base and column provide vibration damping that is ten times more effective than conventional cast iron, enabling superior surface finish and extended tool life. Standard equipment includes a 12-station automatic tool changer, full splash and chip enclosure, and dual chip conveyors. Options include a live spindle with C-axis, part and tool probe systems, and manual or hydraulic chucks with automatic chuck changers. The V40 was developed for aerospace component machining and tire mold production, with installations at customers such as Allied Signal (now Honeywell) and Sikorsky Aircraft.
The V60L steps up to a 66-inch chuck, 68-inch turning diameter, and 70-inch maximum swing with 50 HP at 350 RPM. The 32-tool ATC, moveable rail, and CAT 50 live tooling with C-axis at 2,500 RPM provide full multi-tasking capability for completing complex parts in a single setup. At 58,000 pounds, the V60L delivers the mass and rigidity required for heavy turning of aerospace structures, energy components, and large industrial parts.
Olympia HT-Series CNC Horizontal Boring Mills
The HT120X100 is Olympia's largest standard horizontal table-type boring mill, with a 5-inch boring spindle, 47 by 63-inch table rated at 20,000 pounds, and axis travels of 118 inches (X), 98 inches (Y), 51 inches (Z), and 27.5 inches (W quill). A full 4th-axis rotary table is included for multi-sided machining of castings, forgings, and fabricated structures. The HT120X80 provides a slightly shorter Y-axis configuration. The HT100X60 serves compact to mid-range horizontal boring applications. All HT-series machines feature heavy-duty spindles, precision linear motion systems, and Fanuc CNC controls. Olympia originally developed these machines to serve aircraft component manufacturers, gas turbine builders, and valve and pump companies.
How to Sell Your Used Olympia
Olympia machines hold strong resale value thanks to Canadian manufacturing quality, polymer casting technology, heavy-duty construction, and consistent demand from aerospace, gas turbine, and defense manufacturers. V-series VTLs with live tooling and HT-series horizontal boring mills are both in demand on the secondary market.
Resell CNC buys used Olympia machines, every model and configuration, nationwide.
- Contact us — call (844) 478-8181 or email sales@resellcnc.com.
- Free appraisal within 24 hours, no obligation.
- Accept the offer — we handle rigging, transport, and logistics.
Frequently Asked Questions About Used Olympia Machines
Are used Olympia machines reliable?
Yes. Olympia Engineering manufactures heavy-duty CNC horizontal boring mills and vertical turning centers in Toronto, Canada, combining decades of machine rebuilding expertise with modern design. Polymer castings (on VTL models) provide superior vibration damping for extended tool life and improved accuracy. Every machine is laser-calibrated before delivery and was originally backed by a 3-year parts and labor warranty.
What should I inspect before buying a used Olympia?
On VTLs, test table flatness, spindle condition, live tooling function, and ATC reliability. On horizontal boring mills, verify boring spindle runout, all axis positioning accuracy, quill deflection, and rotary table indexing. On all machines, test the Fanuc control, coolant delivery, and chip management systems.
What Olympia models hold their value best?
V60L live-tooled VTLs maintain the strongest resale values due to multi-tasking capability and aerospace demand. HT120X100 horizontal boring mills with rotary tables also hold well. Call (844) 478-8181 for current valuations.
Does Resell CNC offer financing on used Olympia machines?
Yes. Resell CNC offers flexible financing options to help your business acquire the equipment it needs. Contact us at (844) 478-8181 to discuss terms.
How do I sell my used Olympia?
Contact Resell CNC at (844) 478-8181 or sales@resellcnc.com. We buy all Olympia models nationwide, from V40 vertical turning centers through V60L live-tooled VTLs and HT-series horizontal boring mills. Free appraisal within 24 hours.
