What to Look for When Buying a Used Takamaz
Takamaz lathes are engineered around the Japanese tradition of compact, high-precision turning, with integrated loaders and robot-ready designs that make them a long-standing favorite for unattended production cells. A well-maintained Takamaz delivers years of reliable, consistent service. Here is what to inspect on used units.
Inspect the spindle, sub-spindle, and chuck. Test main spindle runout, listen for bearing noise across the full RPM range, and verify thermal stability after warm-up. On sub-spindle models (XW Series, XT-6T) test the part transfer cycle for repeatability and concentricity. Check chuck condition (main and sub) and jaws for wear, and confirm hydraulic pressure and clamping. On gang-type GSL machines, verify the gang plate, tool slide, and rapid-positioning motion.
Verify the turret(s), live tooling, and Y-axis if equipped. Cycle each turret position and check indexing time, clamping, and runout. On twin-turret XW machines, verify both turrets operate independently and that simultaneous machining cycles are working. On live-tool models (XT-6M, XW-130M, XW-60M), test each driven tool position for smooth, powerful rotation. On Y-axis machines, check axis calibration and backlash.
Inspect the integrated loader and automation. Many Takamaz machines come with built-in gantry loaders, robot interfaces, or bar feeders that add significant value. Verify loader cycle time, gripper condition, and part-handling accuracy. Confirm that any robot integration is functional and that program backups for the loader and robot transfer with the machine.
Identify the Fanuc CNC control and software. Takamaz machines almost universally ship with Fanuc CNC controls. Confirm the Fanuc control series (Series 0i, 30i, or other), software version, and any installed options including probing, tool monitoring, and automation interfaces. Verify parameter backups and any custom macros for the loader or robot transfer with the machine.
Takamaz Machine Series
XL Series (Standard Single-Spindle Lathes)
The XL Series (XL-100, XL-150) is Takamaz's standard single-spindle precision lathe platform and the foundation of the brand's reputation. XL Series machines emphasize the rigidity, accuracy, and longevity that have made TAKAMAZ a long-standing choice for automotive part production cells.
XT Series (Production Turning)
The XT Series (XT-6, XT-6M, XT-6T, XT-6 HS, XT-8) is Takamaz's higher-capacity production turning platform. The XT-6 is the foundation machine, with the XT-6M adding live tooling (milling capability), the XT-6T adding a sub-spindle, and the XT-6 HS adding high-speed configuration. The XT-8 covers larger turning capacity for the same family.
XW Series (Twin-Spindle Two-Turret Compound)
The XW Series (XW-60, XW-60M, XW-130, XW-130M, XW-200) is Takamaz's flagship twin-spindle two-turret compound lathe platform. XW machines deliver simultaneous machining of both sides of a part or two parts at once, packing the functions of two units into a single compact footprint for complete-process production turning.
GSL Series (Gang-Type Precision Lathes)
The GSL Series (GSL-10, GSL-10H, GSL-15P, GSL-15PT) is Takamaz's gang-type precision lathe family. GSL machines focus on the essentials of high-precision small-part production, with a gang-style tool layout for rapid tool indexing and exceptional cycle times on small turned parts.
XD & XTT Specialty Platforms
The XD-10I is a Takamaz integrated turning specialty machine and the XTT-500 is a Takamaz turning platform for high-volume applications. Both are typically deployed with integrated automation in dedicated production cells, often as multi-machine installations in automotive supplier shops.
How to Sell Your Used Takamaz
Takamaz machines hold strong resale value thanks to Japanese build quality, the integrated loader and automation packages, and active demand from automotive, electronics, and medical production shops. XL, XT, XW, and GSL machines are in steady demand on the used market.
Resell CNC buys used Takamaz machines, every model and every generation, nationwide.
- Contact us at (844) 478-8181 or sales@resellcnc.com.
- Free appraisal within 24 hours, no obligation.
- Accept the offer and we handle rigging, transport, and logistics.
Frequently Asked Questions About Used Takamaz Machines
Is Takamaz the same as Takamatsu Machinery?
Yes. TAKAMAZ is the brand name used by Takamatsu Machinery Co., Ltd., a Japanese machine tool builder founded in 1948 and headquartered in Hakusan City, Ishikawa, Japan. Both names refer to the same manufacturer.
Are used Takamaz lathes reliable?
Yes. Takamaz has built CNC precision lathes since the early days of the CNC era and the brand has produced over 30,000 machines cumulatively. Takamaz lathes are renowned for accuracy, rigidity, and longevity, with many older machines still running production after decades of service.
What CNC control do Takamaz machines use?
Fanuc. Across the XL, XT, XW, GSL, XD, and XTT lineups, Takamaz machines almost universally ship with Fanuc CNC controls. Verify the exact Fanuc series and software version on any specific used machine.
What is the difference between the XL, XT, XW, and GSL Series?
XL is Takamaz's standard single-spindle precision lathe platform. XT adds higher capacity with live tooling and sub-spindle options. XW is the twin-spindle two-turret compound platform for simultaneous machining. GSL is the gang-type precision platform for high-speed small-part work.
What should I inspect on a used Takamaz?
Spindle and sub-spindle runout, chuck and jaw condition, turret indexing and live-tool function, Y-axis calibration if equipped, integrated loader or robot interface, Fanuc control series and software version, and parameter and macro backups for both the lathe and any automation.
Why are Takamaz lathes popular in automotive production?
Takamaz machines are engineered around compact footprints with integrated loaders and robot-ready designs, which makes them ideal for unattended production cells. Automotive parts manufacturers value the combination of Japanese precision, small floor space per spindle, and built-in automation capability.
What Takamaz models hold their value best?
XW Series twin-spindle two-turret machines and XT Series live-tooling lathes hold premium resale values. XL Series single-spindle and GSL gang-type lathes also trade actively. Machines bundled with their original loader or robot cell command higher prices than bare lathes.
How do I sell my used Takamaz?
Contact Resell CNC at (844) 478-8181 or sales@resellcnc.com. We buy every Takamaz model and generation: XL, XT, XW, GSL, XD, and XTT, including bundled loaders, robot cells, and bar feeders. Free appraisal within 24 hours.
